1000 tons grain silo
Machine type：TCK 24723
Product introduce：Product Application
HKB series 1000 Ton Grain Silos are widely used in various industrial lines such as grain depot, farm, wooden pellets, sawdust, plastic pellet, seed, sand, flour, starch, oil, feed, water storage, alcohol, wine, port, chemistr
Use range：grain depot, farm, wooden pellets, sawdust, plastic pellet, seed and so on.
Product introduction
Product Application
HKB series 1000 Ton Grain Silos are widely used in various industrial lines such as grain depot, farm, wooden pellets, sawdust, plastic pellet, seed, sand, flour, starch, oil, feed, water storage, alcohol, wine, port, chemistry and so on, which are the very equipments for storage of granular and powder materials.
Complete grain storage, aeration, temperature monitoring, the level indicating, cleaning, drying, other handling and processing systems available.
Haokebang Silo is widely used for
grain storage such as
wheat,
corn,
soybean,
paddy,
rice,
soybean meal,
barley,
malt,
sunflower seeds,
rapeseed,
peanuts,
flour, and other powder materials,
oat, special Silo, and
seeds, etc.
The grain silo is equipped with a ventilation temperature control system to ensure that the grain is stored in good condition and is not moldy.
.jpg)
Features of 1000 Ton Grain Silos.
1. Nice appearance; small volume; simple structure
2. Such small 1000 Ton Grain Silos are used widely in farms.
3. Small capacity can satisfy daily feeding requirement.
4. Even they can be installed inside of the workshop.
5. For silo loading, users can fill silos by inclined movable screw or belt conveyor.
Installation of 1000 Ton Grain Silos
The installation of Soybean Meal Silo can be carried out in different ways.
*If the client wants to install steel silo by themselves, we could offer detailed instruction, and we'll give our quickest response to deal with any question in the process.
*We could also send our engineer to supervise the installation of Grain Silos process. The client could find local workers for the installation work and our engineer will help them during the process.
*If the client needs, we could send our steel silo installation team for the whole installation issue
Contact Supplier
Working principle
1. 1000 Ton Grain Storage Silo roof
Silo roof is made of galvanizing sheet.
Silo roof vent,ladder,manhole,safety handrail is set on the roof as our standard design.
2. 1000 Ton Grain Silo body
The grain silo bin is made of high quality hot-dip galvanizing steel sheet corrugated by special equipments, Body sheets are connected by high yeild bolts, the thickness of silo sheet is designed according to the constant strength theory. There are stiffeners fixed on the body ,which is used to bear the vertical friction force and support the grain silo body;The bolts and nuts are fixed with spherical waterproof washers. There are Aviation special waterproof rubber strip between the silo sheets. The grain silo is equipped with round door, inside and outside ladder, ladder protecting wire net and ladder platform.
3. 1000 Ton Grain Silo bottom fundation:
Silo bottom fundation is made of concrete. We will give you the foundation design according to your soil test and you make the foundation by yourself.
4.1000 Ton Grain Storage Silo Wind Ring:
Wind ring and brackets reduce bolt holes in stiffeners; swaged technology ensure silo power load capacity.
5.Wide Flange I-Beam Support Structure:
Wide flange I-Beam support structure has the strength and durability to support the heavy hopper silo loads long time, and with consideration of wind,snow, seismic requirements.
Technical parameters
| silo type |
Flat bottom silo |
Hopper bottom silo |
| Bottom Cone Degree |
|
60 degree |
45 degree |
| Diameter |
3.6m-20.1m |
1.8m-7.334m |
1.8m-11m |
| Capacity |
30t-10682t |
5.8t-755t |
5.4t-1428t |
| Volume |
39m3-13873m3 |
8.4m3-701m3 |
7.2m3-1855m3 |
Silo Discharge
|
There will be one or more discharge holes on the bottom based on different materials and capacity. |
| Sweeper |
Clean up residual easier |
| auxiliary system |
Temperature control, ventilation system, to ensure that the food is not moldy |
Technical parameters change, no further notice.
